RC Model / FPV Racing Drones Super High Rate Small Capacity Cell

Description

The Super High Rate Small Capacity Cell is MidlandsPower’s pinnacle achievement in high-rate LiPo technology — purpose-built for FPV racing, RC aircraft, car models, ship models, and gun models where split-second power delivery and minimal weight are mission-critical.
Leveraging industry-leading lamination technology, the cell generates microsecond-level strong pulse currents, supporting up to 160 °C pulse discharge and 60 °C continuous discharge. This exceptional rate capability translates directly into the explosive, high-dynamic power output that competitive racing and precision-controlled equipment demand.
Extreme lightweight construction gives this cell a racing-grade thrust-to-weight ratio, enabling agile handling, stable control, and near-instant throttle response. Its performance credentials are proven at the highest level — having helped racers claim championships at international competitions on multiple occasions.
Safety and longevity are equally prioritized. As the first cell in the industry to combine ceramic diaphragms with PVDF pole pieces, it delivers a structurally robust internal design that remains safe and stable even in extreme operating scenarios, resisting degradation where conventional cells would falter.
Backed by 20 years of serving global customers across stringent markets, the Super High Rate Small Capacity Cell is available in capacities from 800mAh to 10,000mAh, spanning multiple voltages and material options. Standard sizing covers 90% of mainstream product compatibility, with deep customization available for specialized applications — from entry-level cost-effective models to full racing-grade configurations.

— HOT SELLING MODELS LIST —

W*L(mm)	Voltage	Capacity	Rate	Thickness(mm)	Weight(g±5%)
20*96mm	3.7V	800mAh	2C/60C/110C	5mm	19g
20*96mm	3.7V	1000mAh	2C/60C/110C	5.5mm	22g
20*122mm	3.7V	1000mAh	2C/60C/110C	5mm	22g
20*122mm	3.7V	1300mAh	2C/60C/110C	6mm	27g
30*48mm	3.7V	500mAh	2C/60C/130C	4.8mm	17g
30*48mm	3.7V	850mAh	2C/60C/130C	7.6mm	26g
30*48mm	3.7V	1100mAh	2C/60C/130C	9.6mm	33g
34*62mm	3.7V	1300mAh	2C/60C/130C	7.1mm	33g
34*62mm	3.7V	1500mAh	2C/60C/130C	8mm	38g
34*62mm	3.7V	2000mAh	2C/60C/130C	10.7mm	50g
34*96mm	3.7V	2200mAh	2C/60C/130C	7.9mm	55g
34*96mm	3.7V	2500mAh	2C/60C/130C	8.9mm	62g
34*96mm	3.7V	3000mAh	2C/60C/130C	10.7mm	75g
43*128mm	3.7V	4000mAh	2C/45C/75C	7.2mm	90g
43*128mm	3.7V	5200mAh	2C/45C/75C	9.2mm	116g
43*128mm	3.7V	6300mAh	2C/45C/75C	10.9mm	137g
70*140mm	3.7V	8000mAh	2C/35C/75C	7.9mm	177g
43*128mm	3.8V	6500mAh	2C/20C/35C	9mm	100g
43*128mm	3.8V	8000mAh	2C/20C/35C	10.8mm	135g
60*120mm	3.85V	10000mAh	2C/15C/35C	9.4mm	155g
